Nexus 132 Strap Puller 2-arm
US$137.34 *
Prices plus shipping costs
Ready to go! In your hands soon. (see shipping costs for details)
- Order number: NX010006
- GTIN-13 (EAN) 4046111004250
- Suppliernumber: 132
- Weight: 2.2 Kg
- Customs tariff number: 82055980
- Country of origin (COO):
Germany
✓ Strap-Puller, 2-arms Robust drop-forged design ✓ Strong spindle with fine thread and... more
✓ Strap-Puller, 2-arms Robust drop-forged design
✓ Strong spindle with fine thread and replaceable ball on top for optimal centering
✓Double-ended reversible legs with wide or narrow grip
✓ Self-locking strap construction automatically presses the pulling legs under the part to be removed
| Clamping width external pulling (mm) |  | 40-220 |
| Clamping width internal pulling (mm) |  | - |
| Clamping depth (mm) |  | 130 |
| Max. torque (Nm) |  | 60 |
| Spindle dimensions (mm) |  | M18x1.5x240 |
| Max. load (t) |  | 4.0 |
| Wrench size (mm) |  | 19 |
| Internal width of pulling hook (mm) |  | 11 |
| External width of pulling hook (mm) |  | 25 |
| Thickness of pulling hook (mm) |  | 4 |
| Length of pulling hook (mm) |  | 21 |
